Notes conférence

Day 1 : October 5th, 2020.

Presentation :
Presentation : A culture change for the success of BIM implementation

Speaker : Ahmed Ryad Sbartaï - CEO - CONSEIL INNOVATION


NUMÉRIQUE - (C-INNOV).

Définition du BIM :

BIM (building information modeling) est un processus de conception intelligent basé


sur un modèle qui s’enrichit d’informations à travers le cycle de vie complet du
bâtiment.

Ce processus est essentiellement activé par la technologie. sans la technologie le


processus ne peut pas fonctionner, et sans le processus, la technologie a une valeur
limitée ( la preuve, on utilisait la technologie depuis les années 90 mais c’est pas pour
autant qu’on faisait du BIM). Pour profiter pleinement des avantages du BIM, il faut
qu’il soit correctement déployé.

Défis du BIM :

Le BIM est un iceberg, en réalité on ne voit que 15% de cet iceberg, à savoir : une
visualisation 3D, une coordination et de la quantité, et les moyens évidents dont on a
besoin sont : les logiciels, des formations, et du matériel. Mais en réalité on obtient
beaucoup plus que ca, et pour ce faire nous aurons besoins de beaucoup plus de
moyens :
Catégories de modèles qui composent la maquette numériques :

Chaque acteur élabore son ou ses propres modèles dans le but de concourir à la
maquette numérique du bâtiment dans la période dans laquelle il intervient.

La qualité de la maquette numérique est garantie par l’interopérabilité de 3 grandes


catégories de modèles :

1- Géométrique : la représentation 3D dans le sens de la géométrie euclidienne.


2- Analytique : l’analyse qui porte les données systémique de la maquette
numérique, elles sont composées d’éléments mathématiques qui vont affecter
les modèles géométriques : projection, topographie, système, circuit … etc, et
chaque composant : dimension, localisation, orientation. Ainsi que les modèles
d’informations : propriété, paramètre, spécification…etc.
3- Informations : Couvrent les champs des modèles géométriques et analytique,
c’est l’objet d’un modèle d’informations de format open source, par exemple :

L'IFC (Industry Foundation Classes) est le format d'échange standard utilisé communément par
les logiciels permettant le travail en BIM (Building Information Modeling).
Dans l'acceptation du BIM, le format IFC, standard ouvert compréhensible de tous les acteurs de
la construction, organise les objets de l'industrie de la construction autour d'un modèle
informatique 3D : la maquette numérique. Ces objets peuvent contenir des informations sur le
cycle de vie complet d'un bâtiment incluant les débuts (à savoir la conception, la documentation et
la construction), l'exploitation des bâtiments, la gestion des installations (facility management) et,
enfin, la démolition et l'élimination.
L'IFC contient pour chaque objet sa géométrie (s'il en a une) et les informations qui y sont
rattachées (par exemple le coût, des informations sur le fabricant, ...).

Le Green Building XML (ou gbXML) a été développé pour faciliter l'interopérabilité entre une
myriade d'outils de conception ou de développement utilisés dans le bâtiment. Le gbXML a été
introduit comme format d'échange entre de nombreux logiciels de CAO ou d'ingénierie. Ce
standard pourrait réduire les temps de développement d'un bâtiment, et aider à vérifier après la
construction que les objectifs de conception ont bien été respectés.

Le format gbXML ou Green Building XML est utilisé pour faciliter le transfert des propriétés d'un
bâtiment stockées dans un modèle 3D BIM vers les applications de calculs énergétiques. Le format
est aujourd'hui supporté par les principaux éditeurs de logiciels BIM et d'analyses énergétiques, et
est de ce fait devenu le standard de l'industrie.

Grâce au format gbXML, il est possible de transférer les données entre les applications, en évitant
le long transfert manuel des données et leurs risques d'erreur.
Les modèles d’information de 4éme dimension intègrent aussi les données
temporelles, l’unité de temps peut donc alimenter les autres modèles, notamment le
modèle analytique.

Géométrique

Informations Analytique

Implémentation du BIM :

Quelque soit la période du projet, le BIM crée des nouvelle relations entre les acteurs.

Le BIM ne change pas l’organisation de l’entité, mais plutôt la façon dont elle produit
sa valeur ajoutée, la principale nouveauté c’est que le BIM permet de faire travailler
au même temps, ensemble, des personnes qui n’avaient pas l’habitude de travailler
ensemble : le PIC n’est plus une tâche isolée dans l’enchainement des études,
d’exécution et des méthodes pour la construction, l’ingénieur électricité n’entame pas
ses études à la dernière période des études de conception…

1- Implémentation interne :

Déploiement BIM interne « détaché » :

Ce genre de déploiement positionne le BIM comme une division apart, chaque


division reste dans son cham opérationnel habituel, et la division BIM dispose de son
propre modèle et intervient comme un sous traitant dans les autres divisions, ce mode
de déploiement est facile à mettre en œuvre puisqu’il n’impacte pas la fonction des
divisions déjà établies.
Atout : vitesse d’obtention des premiers résultats.

Difficulté : développer une valeur ajoutée qui brille auprès de la direction générale,
mais malheureusement ce n’est pas diffusable dans les autres divisions.

Déploiement BIM interne « global » :

Consiste à procéder à la diffusion du BIM selon une entité d’organisation, le


développement est donc plus long, mais le changement s’effectue de façon en
profondeur, tous les individus sont embarqués dans le déploiement.

Difficulté : la difficulté réside dans le gouvernance du BIM dans chaque division et


dans chaque individu, l’échelle de l’individu dans le déploiement du BIM possède la
modalité de développement connaissances et de compétences.

La démarche présentée repose sur 3 étapes :


Day 2 : October 6th, 2020;

Presentation : Digital Design Review for AEC Projects.

Speaker : Craig Howie - DIGITAL PROJECT DELIVERY LEAD – AECOM.

What’s design review:

Design review is a series of steps which is part of the design process to ensure the
final design/ building meets expectations.

Design review steps:

1- Someone does some work (the originator).


2- The originator checks their own work.
3- Someone else comes in and checks or reviews their work (the reviewer).
4- Some form of discussion takes place between the originator and the reviewer
based on the design that has been presented, corrections and updates are
requested by the reviewer.
5- The agreed corrections and updated are made and checked by the corrector, or
the person that actually has originated the information.
6- That information then goes back to the reviewer to confirm that the updated
and corrections have been made in the way that they were expecting them to
have been made and an approval occurs.

What type of file get checked/reviewed :

- Documents : word, excel, powerpoint….


- Drawing : CAD exports, PDFs.
- Calcumlations : Various formats
- 3D models : Graphical and non graphical information.

These checks/ review need different technologies that work with these file formats :
microsoft teams, sharepoint…
What checks/ reviews need to get done on 3D models :

A 3D model review isn’t just about clash detection : doing clash detection too early in
projects can quickly be counterproductive, you can spend a lot of time doing clashing
when thing are actually still going to change, that results in abortive work.

For 3D models there are essentially 4 types of checks:

- Visual checks : using application such as : BIM 360 coordination which


makes it accessible to the wider project team, so modelers and engineers do
virtual walkthroughs through their models and look for things that don’t look
right.
- *Meta data : the clients are very much asking for meta data and information
within each element, so that therefore we need to check to confirm if we’ve
got a particular wall type, and that wall type has a certain metadata attached to
it to be compliant with our contractual requirements.
(Meta data : information added to the objects in the BIM model, generally as materials and properties
(also called parameters or attributes), provides additional information about the object that can be

included in schedules or extracted from the model),

- Classification : international clients are looking for certain classification


systems, and we need to check to see if we’re complying with those
classification systems.
(A classification system is a method for the distribution of a set of coordinated, organized entities and
hierarchical, making it possible to identify the components of a work. These entities are physical or
intangible objects that are employed in the design, construction, operation and the deconstruction of a
building.
• Example of physical objects: elements, spaces, products.
• Example of intangible objects: phases, services, disciplines, roles.
The classification of these organizations is organized in particular by grouping of objects that have
characteristics or similar behaviors (example: class of "doors").
There is also a structuring according to domains which corresponds to the views of different users
(example: functions, phases, roles, actors, etc.). Classifying data means structuring it in an agreed way
so that different actors can easily find what they need and understand it. A classification system is like a
common language. In BIM, classification lets people, software and machines share and use building
information efficiently and accurately, Different classification systems have been developed for different
types of BIM data and actors, and for different geographic areas and situations : Uniclass 2015,
OmniClass, MasterFormat®, CoClass, CCS),
- LOD checks : to check if your graphical output has the right amount of detail,
and can that particular object be relied on for the stage you’re busy delivering
to.(The Level of Development (LOD) Specification is a reference that enables practitioners in the AEC
Industry to specify and articulate with a high level of clarity, the content and reliability of Building
Information Models (BIMs) at various stages in the design and construction process.
Level of Devlopment
LOD 100 - Concept Design
LOD 200 - Schematic Design
LOD 300 - Detailed Design
LOD 350 - Construction Documentation
LOD 400 - Fabrication & Assembly
LOD 500 - As-Built).

- Clash detection : which should happen sort of midway through projects:


Example : During a construction project, two designers may be working
separately on architectural and electrical models. These two models need to
be coordinated before any construction begins, to help ensure that they fit
together. A clash may occur if, for example, a pipe carrying electrical cables
overlaps with a wall. In this case, one of the models would need to be modified
to remove the overlap, and therefore resolve the clash.
- Best practice modeling checks: running audits on models and opening up
that model before issuing it, and looking at all BPM techniques: is the file size
correct, is there an issue with links and imported CAD files, are the objects in
the model are at a correct quality, did they get the correct naming standart…

Trends and technologies impacting design review in the AEC sector:

1- Virtual reality: a very good technology to digital reviewing : oculus quest


headset, Enscape application, insiteVR….
2- Cloud and automated clash detection: the idea is to put a whole lot of models
into a particular cloud location, and the actual application does the clash
detection, and give you instant feedback on those clashes. An example of
application is BIM360 model coordination, suited to smaller to medium sized
projects that aren’t complicated, and to projects where all the disciplines are
working in Revit, and where the teams have the time to take on doing a level
of clash detection themselves.
3- Automated model audits: currently there are many ways you can do modeling
best practice checks : manually within REVIT (you have an excel
spreadsheet, and it got a serie of checks that you need to go and do and you
manually go and look in REVIT an see if we are compliant, this is clearly not
a practical method). Standalone dynamo script, industry addins, inhouse
addins.
4- Machine learning and self checking: example : ALI : which is a machine
learning algorithms capable of spotting clashing, unconnected, duplicated,
incorrectly sized objects, unclassified, or incorrectly classified components…
so it’s essentially an automated self checking tool

Industry challenges:

- We now spend a lot of time as design consultants reviewing things that


previously would have been dealt with on site or that was commonly not
resolved in a 3D environment (we need to think about designing, on a 3D
model, then once we do all the modifications that can happen on the design,
we move to the 2D design).
- Software vendors are releasing product to market very quickly, that are
sometimes not entirely fit for purpose or refined, they then rely on the industry
feedback to develop their product.
- We’re coordination to a fine level of detail in a virtual environment, however,
when we document and provide drawing, this same level of coordination isn’t
clearly illustrated in our drawing, is it even practical for contractor and their
subcontractor to deliver to that level of accuracy for all elements if we don’t
provide correct dimensions or contractors begin to use models to layout their
construction and installations.
Day 2 : October 6th, 2020;

Presentation : Digital Design Review for AEC Projects.

Speaker : Craig Howie - DIGITAL PROJECT DELIVERY LEAD – AECOM.

Vous aimerez peut-être aussi
