CARRIER FRAME PARTS

115D41939-1
TABLE OF CONTENTS Sandvik DD321-40 150824

8. CARRIER FRAME PARTS

* BG 005 835 21 NSS COMPONENTS, CARRIER FRAME................................................................................................................ 2
** 551 800 58 NSS SCREW KIT, CARRIER FRAME ASSEMBLY.................................................................................................... 9
** 551 800 59 NSS AXLE, ASSEMBLY 1660MM FRONT.................................................................................................................. 10
*** 550 368 63 AXLE, 1660 MM....................................................................................................................................................... 11
**** 550 536 11 NSS DIFFERENTIAL CASE ASSEMBLY (NO DIFFERENTIAL GEARS)............................................................ 12
**** 550 536 39 NSS DIFFERENTIAL & CARRIER ASSEMBLY, DIFFERENTIAL....................................................................... 14
**** 550 549 37 NSS HUB AND SHAFT, HUB REDUCTION........................................................................................................ 16
**** 550 540 16 NSS BRAKE HOUSING ASSEMBLY................................................................................................................... 18
** 551 800 60 NSS AXLE, ASSEMBLY 1660MM REAR.................................................................................................................... 19
*** 550 368 82 AXLE........................................................................................................................................................................ 20
**** 550 540 17 NSS DIFFERENTIAL CASE ASSEMBLY (NO DIFFERENTIAL GEARS)............................................................ 21
**** 550 540 20 NSS DIFFERENTIAL & CARRIER ASSEMBLY, DIFFERENTIAL....................................................................... 24
**** 550 549 35 NSS HUB AND SHAFT, HUB REDUCTION........................................................................................................ 26
**** 550 540 23 NSS BRAKE HOUSING ASSEMBLY................................................................................................................... 28
**** 550 549 36 NSS BEARING ASSEMBLY, TRUNION.............................................................................................................. 29
** 551 796 79 NSS STEERING ASSEMBLY...................................................................................................................................... 32
*** 550 395 19 CYLINDER, 80/50-450............................................................................................................................................. 38
** 552 156 29 NSS PIPE, EXHAUST, MOUNTING............................................................................................................................ 39
** 550 401 34 DRIVE SHAFT, LZ=380............................................................................................................................................... 40
** 550 907 46 DRIVE SHAFT, LZ=640, LA=110................................................................................................................................ 41
** 881 956 69 NSS DRIVE SHAFT, L=1070, UCP............................................................................................................................. 42
** 550 569 81 NSS CABINET, BOX AND FASTENING PARTS........................................................................................................ 43
** 551 799 02 NSS PLATE, COVER, ASSEMBLY, HEAT COVER.................................................................................................... 44
** 551 844 12 WHEEL ASSEMBLY, 12.00-20 PR28 ECR HAULER.................................................................................................. 45
** 551 670 73 NSS ACCUMULATOR, PRESSURE, BRAKES........................................................................................................... 46
** 552 039 05 NSS ASSEMBLY, MEASURING ADAPTERS............................................................................................................. 47
*** 552 037 49 NSS MANIFOLD BLOCK, MEASURING ADAPTERS............................................................................................. 48
** 551 731 90 NSS DIPSTICK KIT, FOR TRANSMISSION OIL CHECK........................................................................................... 49
** 551 735 16 NSS DEFLECTOR, AIR, ASSEMBLY, TOP................................................................................................................ 50
** 551 732 32 NSS DEFLECTOR, AIR, ASSEMBLY, LEFT............................................................................................................... 51
** 551 732 31 NSS DEFLECTOR, AIR, ASSEMBLY, RIGHT............................................................................................................ 52
** 550 398 44 NSS SHIELD, SPLASH, FRONT, LEFT...................................................................................................................... 53
** 550 441 51 NSS SHIELD, SPLASH, FRONT, RIGHT.................................................................................................................... 54
** 551 737 59 NSS MUDGUARD ASSEMBLY, REAR, RIGHT.......................................................................................................... 55
** 551 737 58 NSS MUDGUARD ASSEMBLY, REAR, LEFT............................................................................................................ 56

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 BG 005 835 21 aH NSS
1 (57) COMPONENTS, CARRIER FRAME 150824

51

799 348

555 521

16 578

19

31 29
106
28
500
30 29
570
88
16
34

204 35
523 554 29
376
28
579 5
30 31

3 20

553 553
86
202 512
173
62 207
552

510

144 61 59

506 202 201

551 553 553

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 BG 005 835 21 aH NSS
150824 COMPONENTS, CARRIER FRAME 2 (57)

Ref. Part no. Description EN Standard designation Qty

e
3 552 128 41 NSS ENGINE ASSEMBLY SECTION 9 PAGE 2 1
4 551 800 59 NSS AXLE SECTION 8 PAGE 10 1
5 551 800 60 NSS AXLE SECTION 8 PAGE 19 1
16 551 761 18 LIMITER Turning limiter +- 40 deg 2
19 551 844 12 WHEEL ASSEMBLY SECTION 8 PAGE 45 2
. . . . .
20 551 844 12 WHEEL ASSEMBLY SECTION 8 PAGE 45 2
51 550 399 16 PLATE, LOCKING 2
59 550 871 74 PLATE Air guide plate 1
61 551 732 32 NSS DEFLECTOR, AIR SECTION 8 PAGE 51 1
62 551 732 31 NSS DEFLECTOR, AIR SECTION 8 PAGE 52 1
. . . . .
88 551 805 47 BRACKET Carrier locking pin 1
799 551 800 58 NSS SCREW KIT SECTION 8 PAGE 9 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 BG 005 835 21 aH NSS
3 (57) COMPONENTS, CARRIER FRAME 150824

566 566
350 68 69 350

351 351
566 566

315
556 566
315
590
591
12

50
592
208
593
511
553

11 272

593 517

592 556

55
85
85

592
553
593
201
10 14

590
591

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 BG 005 835 21 aH NSS
150824 COMPONENTS, CARRIER FRAME 4 (57)

Ref. Part no. Description EN Standard designation Qty

e
10 550 401 34 DRIVE SHAFT SECTION 8 PAGE 40 1
11 550 907 46 DRIVE SHAFT SECTION 8 PAGE 41 1
12 881 956 69 NSS DRIVE SHAFT SECTION 8 PAGE 42 1
14 550 518 67 BRACKET 1
50 551 670 73 NSS ACCUMULATOR, PRESSURE SECTION 8 PAGE 46 1
. . . . .
55 551 731 90 NSS DIPSTICK KIT SECTION 8 PAGE 49 1
68 550 465 24 NSS GUIDE, HOSE Front axle, Left 1
69 550 465 43 NSS GUIDE, HOSE Front axle, Right 1
85 551 882 14 NSS PIN Powerpack turning 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 BG 005 835 21 aH NSS
5 (57) COMPONENTS, CARRIER FRAME 150824

81 82 554 205 101

559 357 64 65 357 559

556 262 60

559 354 67 66 354 559 52 147 507 551

55 27 205 553

565 517 270 63 87 202 554

7 270 517 565

83 313 566
566 313 84

552 173 89 204 564

551 141 15
265 565
551 144 89 204 564
552 172 18
56 172 172
555 262

144 93 92 262 555

551 553 205 17

58 145 507 551
13

90
276
555

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 BG 005 835 21 aH NSS
150824 COMPONENTS, CARRIER FRAME 6 (57)

Ref. Part no. Description EN Standard designation Qty

e
7 552 156 29 NSS PIPE, EXHAUST SECTION 8 PAGE 39 1
13 550 569 81 NSS CABINET SECTION 8 PAGE 43 1
15 551 799 02 NSS PLATE, COVER SECTION 8 PAGE 44 1
17 551 687 59 BRACKET Carrier main switch and jump start plug 1
18 551 685 42 BRACKET Fuse box 1
. . . . .
52 552 039 05 NSS ASSEMBLY SECTION 8 PAGE 47 1
55 551 731 90 NSS DIPSTICK KIT SECTION 8 PAGE 49 1
56 551 571 20 BRACKET Oil filler pipe and dipstick 1
58 551 735 16 NSS DEFLECTOR, AIR SECTION 8 PAGE 50 1
60 550 382 44 PLATE, COVER Cardan Carrier 1
. . . . .
63 550 526 24 GUARD Rear frame 1
64 550 445 37 BLOCK, SUPPORTING 1
65 550 445 38 BLOCK, SUPPORTING 1
81 550 398 44 NSS SHIELD, SPLASH SECTION 8 PAGE 53 1
82 550 441 51 NSS SHIELD, SPLASH SECTION 8 PAGE 54 1
. . . . .
83 551 737 59 NSS MUDGUARD ASSEMBLY SECTION 8 PAGE 55 1
84 551 737 58 NSS MUDGUARD ASSEMBLY SECTION 8 PAGE 56 1
87 850 953 99 EDGING PLATE 0.3
92 800 717 79 SWITCH, MAIN 1
93 560 064 91 HANDLE, LOCKING Lockable battery isolator switch assembly 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 BG 005 835 21 aH NSS
7 (57) COMPONENTS, CARRIER FRAME 150824

47

21 25

24 23

27

43 40 33 42 313 85 32 205 47 22 25
172 41 557 553

552

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 BG 005 835 21 aH NSS
150824 COMPONENTS, CARRIER FRAME 8 (57)

Ref. Part no. Description EN Standard designation Qty

e
85 551 882 14 NSS PIN Powerpack turning 2
6 551 796 79 NSS STEERING ASSEMBLY SECTION 8 PAGE 32 1
98 550 162 73 STRAP L=250 Black 30
99 807 695 29 STRAP L=400 Black 30
901 028 688 20 DECAL Engine oil 1
. . . . .
902 028 688 10 DECAL Engine coolant 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 800 58 h NSS
9 (57) SCREW KIT / CARRIER FRAME ASSEMBLY 150824

Ref. Part no. Description EN Standard designation Qty

e
106 737 021 12 SCREW M4X35 - 12.9 4
141 858 719 39 HEXAGON HEAD SCREW M8X12 - 8.8 2
144 808 802 29 HEXAGON HEAD SCREW M8X20 - 8.8 12
145 800 916 09 HEXAGON HEAD SCREW M8X25 - 8.8 6
147 442 577 60 HEXAGON HEAD SCREW M8X35 - 8.8 2
. . . . .
155 808 743 69 HEXAGON HEAD BOLT M8X60-8.8 4
172 800 823 09 HEXAGON HEAD SCREW M10X20 - 8.8 8
173 800 460 49 HEXAGON HEAD SCREW M10X25 - 8.8 6
201 800 194 09 HEXAGON HEAD SCREW M12X20 - 8.8 2
202 800 824 29 HEXAGON HEAD SCREW M12X25 - 8.8 8
. . . . .
204 800 470 59 HEXAGON HEAD SCREW M12X30 - 8.8 4
205 442 776 90 HEXAGON HEAD SCREW M12X35 - 8.8 12
208 800 533 29 HEXAGON HEAD BOLT M12X55 - 8.8 2
262 800 196 59 HEXAGON HEAD SCREW M16X30 - 8.8 8
265 800 538 69 HEXAGON HEAD SCREW M16X45 - 8.8 4
. . . . .
270 801 745 59 HEXAGON HEAD SCREW M16X60 - 8.8 4
272 800 437 09 HEXAGON HEAD BOLT 16X65 - 8.8 2
313 800 167 59 HEXAGON HEAD SCREW M20X40 12
315 442 936 00 HEXAGON HEAD SCREW M24x60 - 8.8 6
348 881 957 99 BOLT M20X280 8
. . . . .
350 819 985 49 HEXAGON HEAD SCREW M24x30 m8.8 4
351 442 934 50 HEXAGON HEAD SCREW M24X40 m8.8 8
354 442 936 00 HEXAGON HEAD SCREW M24x60 - 8.8 14
357 442 325 00 HEXAGON HEAD BOLT M24x80 8.8 14
376 550 398 46 HEXAGON HEAD BOLT M24x220 - 10.9 4
. . . . .
500 801 773 29 NUT, LOCK M4 - 8 4
507 800 917 29 NUT, HEXAGON M8 - 8 12
511 412 113 00 NUT, LOCK M12 - 8 , Zn 2
517 801 775 89 NUT, LOCK M16 - 8 6
521 817 807 89 NUT, LOCK M20 - 8 16
. . . . .
523 550 358 20 NUT, HEXAGON M24 - 10.9 8
551 851 281 89 WASHER, LOCK, DOUBLE M8 26
552 550 130 58 WASHER, LOCK, DOUBLE M10 sp 12
553 851 068 09 WASHER, LOCK, DOUBLE M12 18
554 550 130 59 WASHER, LOCK, DOUBLE M12 sp 6
. . . . .
555 850 687 49 WASHER, LOCK, DOUBLE M16 4
556 550 130 61 WASHER, LOCK, DOUBLE M16 sp 20
557 550 130 63 WASHER, LOCK, DOUBLE M20 sp 2
559 550 130 65 WASHER, LOCK, DOUBLE M24 sp 28
564 550 130 59 WASHER, LOCK, DOUBLE M12 sp 2
. . . . .
566 550 130 63 WASHER, LOCK, DOUBLE M20 sp 23
570 421 155 10 WASHER 4,3 8
578 421 205 00 WASHER M21 16
579 421 211 00 WASHER M25 8
590 550 443 82 HEXAGON HEAD SCREW M10X30 - 10.9 16
. . . . .
591 550 443 79 NUT, HEX., PREVAILING TORQUE, ALL M12 m8 BH8 16
METAL
592 550 443 83 HEXAGON HEAD SCREW M12X35 - 10.9 24
593 550 443 77 NUT, LOCK M12 m8 BH8 24
799 445 854 70 HEXAGON SOCKET HEAD SCREW M16X30 4

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 800 59 aA NSS
150824 AXLE / ASSEMBLY 1660MM FRONT 10 (57)

71 72 70 70 71

75 76

70 71

70 72 71

Ref. Part no. Description EN Standard designation Qty

e
4 550 368 63 AXLE SECTION 8 PAGE 11 1
70 550 444 32 STRAIGHT THREAD ADAPTER M14x1,5 / JIC 3/4-16 4
71 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 4
72 817 163 39 ADAPTER, TEE 3/4-16 JIC 2
75 817 169 09 STRAIGHT THREAD ADAPTER JIC 7/16-20 1
. . . . .
76 819 561 09 SWIVEL NUT ELBOW 90 JIC 7/16-20 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 368 63 b
11 (57) AXLE / 1660 MM 150824

Ref. Part no. Description EN Standard designation Qty

e
*1 550 536 11 NSS DIFFERENTIAL CASE ASSEMBLY (NO SECTION 8 PAGE 12
DIFFERENTIAL GEARS)
*2 550 536 39 NSS DIFFERENTIAL & CARRIER ASSEMBLY SECTION 8 PAGE 14
*3 550 549 37 NSS HUB AND SHAFT SECTION 8 PAGE 16
*4 550 540 16 NSS BRAKE HOUSING ASSEMBLY SECTION 8 PAGE 18

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 536 11 a NSS
150824 DIFFERENTIAL CASE ASSEMBLY (NO DIFFERENTIAL GEARS) 12 (57)

1 2

6 7 8
4

10

Ref. Part no. Description EN Standard designation Qty

e
1 550 536 12 O-RING 2
2 550 543 04 VALVE 1
3 550 536 14 COVER INTERMEDIATE COVER 1
4 550 536 15 O-RING 1
5 550 536 21 BOLT 4
. . . . .
6 550 536 22 PLUG 1
7 550 536 27 PLUG 1
8 550 536 28 CIRCLIP 1
9 551 744 19 PLUG Magnet plug 1
10 550 536 30 HOUSING 1
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 536 39 b NSS
13 (57) DIFFERENTIAL & CARRIER ASSEMBLY / DIFFERENTIAL 150824

1
24 POSITION KIT = 5+7+8+9+10+11+12

22 25 OPTIONAL 2
12

7 24

9
10 5

8
11

10
10
9

8 9

13

14

4 6 15
21

3 5
16
2 20
22
23
1 19

17
25
18

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 536 39 b NSS
150824 DIFFERENTIAL & CARRIER ASSEMBLY / DIFFERENTIAL 14 (57)

Ref. Part no. Description EN Standard designation Qty

e
1 550 536 41 BOLT CYLINDER BOLT 2
2 550 536 43 NUT RING NUT 2
3 550 536 45 BEARING TAPER ROLLER BEARING 2
4 550 536 47 BOLT 16
5 550 536 48 DIFFERENTIAL ASSEMBLY (NO PINION & 1
RING GEAR)
. . . . .
6 550 536 50 RING GEAR AND PINION KIT BEVEL GEAR SET 1
7 550 536 52 WASHER FRICTION WASHER 2
8 550 536 53 GEAR WHEEL DIFFERENTIAL SIDE GEAR 2
9 550 900 48 DISC, FRICTION 4
10 550 536 55 GEAR WHEEL DIFFERENTIAL PINION 4
. . . . .
11 550 536 56 PIN 2
12 550 536 57 BOLT 12
13 550 536 58 BEARING TAPER ROLLER BEARING 1
14.1 550 536 67 SHIM 1
14.2 550 884 84 SHIM 1
. . . . .
14.3 550 884 87 SHIM 1
14.4 550 884 88 SHIM 1
14.5 550 884 89 SHIM 1
15 550 536 68 SPACER 1
16 550 536 69 SEAL 1
. . . . .
17 550 536 70 O-RING 1
18 550 536 71 NUT 1
19 550 536 75 PLATE, COVER 1
20 550 536 77 BEARING TAPER ROLLER BEARING 1
21.1 550 536 79 SHIM 1
. . . . .
21.2 550 884 81 SHIM 1
21.3 550 884 82 SHIM 1
21.4 550 884 83 SHIM 1
23 550 182 84 FLANGE 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 549 37 aA NSS
15 (57) HUB AND SHAFT / HUB REDUCTION 150824

8 X
11 12

10

4
8
31
7

17 18

16

15

6
14
1 5
13
30

3 19
23
20
2
24
32

33
27
21

28 22

2
25

26
18

34

29

30 31 OPTIONAL

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 549 37 aA NSS
150824 HUB AND SHAFT / HUB REDUCTION 16 (57)

Ref. Part no. Description EN Standard designation Qty

e
1 550 543 01 HOUSING, AXLE 2
2 550 536 90 WASHER 32
3 550 536 95 BOLT HEXAGON BOLT 24
4 550 543 02 SHAFT Half shaft 2
5 550 536 97 SEAL 2
. . . . .
6 551 744 13 RING CENTERING RING 2
7 550 537 13 SEAL 2
8 550 537 19 BEARING TAPER ROLLER BEARING 4
9 550 537 26 STUD WHEEL STUD 20
10 550 537 28 HUB WHEEL HUB 2
. . . . .
11 550 537 29 NUT WHEEL NUT 20
12 550 536 15 O-RING 2
13 550 537 31 SEAL 6
14 550 537 32 GEAR, PLANETARY 6
15 550 537 33 BEARING 6
. . . . .
16 550 670 15 PLANET GEAR ASSEMBLY INCL. PARTS 13-15, 17 2
17 550 670 16 HOUSING PLANET GEAR CARRIER 2
18 550 536 22 PLUG 4
19 550 537 35 BOLT COUNTERSUNK BOLT 4
20 550 537 36 WASHER FRICTION WASHER 2
. . . . .
21 550 537 37 NUT 16
22 550 537 38 STUD STUD 16
23 550 537 39 LOCK DEVICE 2
24 550 537 44 GEAR WHEEL RING GEAR SUPPORT 2
25 550 670 17 GEAR, RING 2
. . . . .
26 550 537 41 CIRCLIP 2
27 551 744 19 PLUG Magnet plug 2
28 550 537 42 NUT 8
29 550 537 43 STUD STUD 8
33 550 670 18 GEAR WHEEL RING GEAR SUPPORT KIT INCL. PARTS 2
24-26
. . . . .
34 550 536 12 O-RING 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 540 16 c NSS
17 (57) BRAKE HOUSING ASSEMBLY 150824

16

15

14

13

12
17

18
11

10 27

9 26
8 19
25
7

6
5
4 24

3 20
21
23

22

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 540 16 c NSS
150824 BRAKE HOUSING ASSEMBLY 18 (57)

Ref. Part no. Description EN Standard designation Qty

e
1 550 537 46 SPRING 2
2 550 536 12 O-RING 2
3 550 537 47 PISTON 2
4 550 537 48 BACK UP RING 4
5 550 537 49 BLEED SCREW 4
. . . . .
6 550 537 50 PLUG 4
7 550 537 51 BOLT 4
8 550 537 52 WASHER, SEAL 4
9 550 537 53 O-RING 2
10 550 537 54 BACK UP RING 2
. . . . .
11 550 537 55 PISTON 2
12 550 537 56 SPRING 6
13 550 537 57 BOLT 6
14 550 537 58 DISC, BRAKE INTERMEDIATE BRAKE DISC 6
15 550 548 83 DISC, BRAKE BRAKE DISC 6
. . . . .
16 550 670 11 HUB, CLUTCH SELECTOR 2
17 551 638 54 SCREW, ADJUSTING 6
18 550 538 46 SPRING 6
19 550 538 47 DISC, BRAKE INTERMEDIATE BRAKE DISC 2
20 550 538 49 COVER 2
. . . . .
21 550 538 50 O-RING 4
23 550 538 53 SPACER 2
24.1 550 538 57 SHIM 2
24.2 551 542 50 SHIM 2
24.3 551 542 54 SHIM 2
. . . . .
25 550 538 58 WASHER, LOCK 4
26 550 538 59 NUT 4
27 550 538 61 BOLT 4

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 800 60 NSS
19 (57) AXLE / ASSEMBLY 1660MM REAR 150824

75
77
76
70
71
70

70
77

70
71

Ref. Part no. Description EN Standard designation Qty

e
5 550 368 82 AXLE SECTION 8 PAGE 20 1
70 550 444 32 STRAIGHT THREAD ADAPTER M14x1,5 / JIC 3/4-16 4
71 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 2
75 817 169 09 STRAIGHT THREAD ADAPTER JIC 7/16-20 1
76 819 561 09 SWIVEL NUT ELBOW 90 JIC 7/16-20 1
. . . . .
77 858 881 09 ADAPTER, TEE JIC 3/4-16 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 368 82 c
150824 AXLE 20 (57)

1 2 3 4 5

Ref. Part no. Description EN Standard designation Qty

e
*1 550 540 17 NSS DIFFERENTIAL CASE ASSEMBLY (NO SECTION 8 PAGE 21
DIFFERENTIAL GEARS)
*2 550 540 20 NSS DIFFERENTIAL & CARRIER ASSEMBLY SECTION 8 PAGE 24
*3 550 549 35 NSS HUB AND SHAFT SECTION 8 PAGE 26
*4 550 540 23 NSS BRAKE HOUSING ASSEMBLY SECTION 8 PAGE 28
*5 550 549 36 NSS BEARING ASSEMBLY SECTION 8 PAGE 29
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 540 17 a NSS
21 (57) DIFFERENTIAL CASE ASSEMBLY (NO DIFFERENTIAL GEARS) 150824

1 2

3 8 11

4 6 7

10

Ref. Part no. Description EN Standard designation Qty

e
1 550 536 12 O-RING 2
2 550 543 04 VALVE 1
3 550 536 14 COVER INTERMEDIATE COVER 1
4 550 536 15 O-RING 1
5 550 536 21 BOLT 4
. . . . .
6 550 536 22 PLUG 1
7 550 538 62 O-RING 1
8 550 670 13 SUPPORT 1
9 551 744 19 PLUG Magnet plug 1
10 550 670 14 HOUSING 1
. . . . .
11 550 538 69 BOLT CYLINDER BOLT 8

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 540 20 a NSS
23 (57) DIFFERENTIAL & CARRIER ASSEMBLY / DIFFERENTIAL 150824

1
24 POSITION KIT = 5+7+8+9+10+11+12

22 25 OPTIONAL 2
12

7 24

9
10 5

8
11

10
10
9

8 9

13

14

4 6 15
21

3 5
16
2 20
22
23
1 19

17
25
18

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 540 20 a NSS
150824 DIFFERENTIAL & CARRIER ASSEMBLY / DIFFERENTIAL 24 (57)

Ref. Part no. Description EN Standard designation Qty

e
1 550 536 41 BOLT CYLINDER BOLT 2
2 550 536 43 NUT RING NUT 2
3 550 536 45 BEARING TAPER ROLLER BEARING 2
4 550 536 47 BOLT 16
5 550 536 48 DIFFERENTIAL ASSEMBLY (NO PINION & 1
RING GEAR)
. . . . .
6 550 536 50 RING GEAR AND PINION KIT BEVEL GEAR SET 1
7 550 536 52 WASHER FRICTION WASHER 2
8 550 536 53 GEAR WHEEL DIFFERENTIAL SIDE GEAR 2
9 550 900 48 DISC, FRICTION 4
10 550 536 55 GEAR WHEEL DIFFERENTIAL PINION 4
. . . . .
11 550 536 56 PIN 2
12 550 536 57 BOLT 15
13 550 536 58 BEARING TAPER ROLLER BEARING 1
14.1 550 536 67 SHIM 1
14.2 550 884 84 SHIM 1
. . . . .
14.3 550 884 87 SHIM 1
14.4 550 884 88 SHIM 1
14.5 550 884 89 SHIM 1
15 550 536 68 SPACER 1
16 550 536 69 SEAL 1
. . . . .
17 550 536 70 O-RING 1
18 550 536 71 NUT 1
19 550 536 75 PLATE, COVER 1
20 550 536 77 BEARING TAPER ROLLER BEARING 1
21.1 550 536 79 SHIM 1
. . . . .
21.2 550 884 81 SHIM 1
21.3 550 884 82 SHIM 1
21.4 550 884 83 SHIM 1
23 550 182 84 FLANGE 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 549 35 aA NSS
25 (57) HUB AND SHAFT / HUB REDUCTION 150824

12 X 8
11

10

4
8
31 LONG
7

17 18

16
15
6
1 14
5
30 LONG 13
(or special)

3
19
20
23
2
32
24

27 33
21

28 22

2
25

18 26

34

29 30 31 OPTIONAL

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 549 35 aA NSS
150824 HUB AND SHAFT / HUB REDUCTION 26 (57)

Ref. Part no. Description EN Standard designation Qty

e
1 550 538 71 HOUSING, AXLE AXLE CASE 2
2 550 536 90 WASHER 32
3 550 536 95 BOLT HEXAGON BOLT 24
4 550 538 72 SHAFT HALF SHAFT 2
5 550 536 97 SEAL 2
. . . . .
6 551 744 13 RING CENTERING RING 2
7 550 537 13 SEAL 2
8 550 537 19 BEARING TAPER ROLLER BEARING 4
9 550 537 26 STUD WHEEL STUD 20
10 550 537 28 HUB WHEEL HUB 2
. . . . .
11 550 537 29 NUT WHEEL NUT 20
12 550 536 15 O-RING 2
13 550 537 31 SEAL 6
14 550 537 32 GEAR, PLANETARY 6
15 550 537 33 BEARING 6
. . . . .
16 550 670 15 PLANET GEAR ASSEMBLY INCL. PARTS 13-15, 17 2
17 550 670 16 HOUSING PLANET GEAR CARRIER 2
18 550 536 22 PLUG 2
19 550 537 35 BOLT COUNTERSUNK BOLT 4
20 550 537 36 WASHER FRICTION WASHER 2
. . . . .
21 550 537 37 NUT 16
22 550 537 38 STUD STUD 16
23 550 537 39 LOCK DEVICE 2
24 550 537 44 GEAR WHEEL RING GEAR SUPPORT 2
25 550 670 17 GEAR, RING 2
. . . . .
26 550 537 41 CIRCLIP 2
27 551 744 19 PLUG Magnet plug 2
28 550 537 42 NUT 8
29 550 537 43 STUD STUD 8
33 550 670 18 GEAR WHEEL RING GEAR SUPPORT KIT INCL. PARTS 2
24-26
. . . . .
34 550 536 12 O-RING 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 540 23 c NSS
27 (57) BRAKE HOUSING ASSEMBLY 150824

16

15

14

13

12

17

18 27

11

10
19
9 26
7 8

25

24
6 5 4
20

X 23
3 21

22

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 540 23 c NSS
150824 BRAKE HOUSING ASSEMBLY 28 (57)

Ref. Part no. Description EN Standard designation Qty

e
1 550 537 46 SPRING 2
2 550 536 12 O-RING 2
3 550 537 47 PISTON 2
4 550 537 48 BACK UP RING 4
5 550 537 49 BLEED SCREW 4
. . . . .
6 550 537 50 PLUG 4
7 550 537 51 BOLT 4
8 550 537 52 WASHER, SEAL 4
9 550 537 53 O-RING 2
10 550 537 54 BACK UP RING 2
. . . . .
11 550 537 55 PISTON 2
12 550 537 56 SPRING 6
13 550 537 57 BOLT 6
14 550 537 58 DISC, BRAKE INTERMEDIATE BRAKE DISC 6
15 550 548 83 DISC, BRAKE BRAKE DISC 6
. . . . .
16 550 670 11 HUB, CLUTCH SELECTOR 2
17 551 638 54 SCREW, ADJUSTING 6
18 550 538 46 SPRING 6
19 550 538 47 DISC, BRAKE INTERMEDIATE BRAKE DISC 2
20 550 538 49 COVER 2
. . . . .
21 550 538 50 O-RING 4
23 550 538 53 SPACER 2
24.1 550 538 57 SHIM 2
24.2 551 542 50 SHIM 2
24.3 551 542 54 SHIM 2
. . . . .
25 550 538 58 WASHER, LOCK 4
26 550 538 59 NUT 4
27 550 538 61 BOLT 4

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 549 36 a NSS
29 (57) BEARING ASSEMBLY / TRUNION 150824

6 2
1
3

4
5

Ref. Part no. Description EN Standard designation Qty

e
1 550 538 88 BUSHING REDUCTION BUSHING 4
2 550 538 89 BUSHING THRUST BUSHING 2
3 550 539 97 SUPPORT 2
4 550 538 91 NIPPLE, GREASE GREASE FITTING 2
5 550 537 50 PLUG 2
. . . . .
6 550 539 98 SUPPORT Incl. part 1-5 INCL. PARTS 1-5 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 796 79 hH NSS
31 (57) STEERING ASSEMBLY 150824

51

799 348

555 521

16 578

19

31 29
106
28
500
30 29
570
88
16
34

204 35
523 554 29
376
28
579 5
30 31

3 20

553 553
86
202 512
173
62 207
552

510

144 61 59

506 202 201

551 553 553

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 796 79 hH NSS
150824 STEERING ASSEMBLY 32 (57)

Ref. Part no. Description EN Standard designation Qty

e
28 551 797 91 SUPPORT, TRANSPORT Carrier turning lock 1
29 814 926 79 PIN D=4 4
30 551 889 97 PIN Carrier turning lock 1
31 551 889 96 PIN Carrier turning lock 1
34 551 798 41 PIN Carrier turning lock 1
. . . . .
35 551 798 42 PIN Carrier turning lock 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 796 79 hH NSS
33 (57) STEERING ASSEMBLY 150824

81 82 554 205 101

559 357 64 65 357 559

556 262 60

559 354 67 66 354 559 52 147 507 551

55 27 205 553

565 517 270 63 87 202 554

7 270 517 565

83 313 566
566 313 84

552 173 89 204 564

551 141 15
265 565
551 144 89 204 564
552 172 18
56 172 172
555 262

144 93 92 262 555

551 553 205 17

58 145 507 551
13

90
276
555

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 796 79 hH NSS
150824 STEERING ASSEMBLY 34 (57)

Ref. Part no. Description EN Standard designation Qty

e
27 550 251 62 HOSE SUPPORT ASSEMBLY 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 796 79 hH NSS
35 (57) STEERING ASSEMBLY 150824

47

21 25

24 23

27

43 40 33 42 313 85 32 205 47 22 25
172 41 557 553

552

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 796 79 hH NSS
150824 STEERING ASSEMBLY 36 (57)

Ref. Part no. Description EN Standard designation Qty

e
21 550 239 81 PIN 1
22 550 239 82 PIN 1
23 550 239 93 SPACER 2
24 550 239 94 PLATE, BEARING 2
25 550 572 59 BEARING, SPHERICAL, PLAIN D130 d90 L60 2
. . . . .
27 550 251 62 HOSE SUPPORT ASSEMBLY 1
32 817 098 79 STRAIGHT THREAD ELBOW G 1/2 x JIC 3/4-16 2
33 615 041 09 ADAPTER, TEE 3/4x1/2x3/4 2
40 550 233 90 BUSHING D48 d40 L20 8
41 550 388 33 PIN steering cylinder 4
. . . . .
42 550 395 19 CYLINDER SECTION 8 PAGE 38 2
43 550 388 36 PLATE locking plate 4
47 865 683 09 PLUG G1/8 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 395 19 b
37 (57) CYLINDER / 80/50-450 150824

14
12
1

13
5

3
10
8
9
6
4

11
7

2
14

12

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 395 19 b
150824 CYLINDER / 80/50-450 38 (57)

Ref. Part no. Description EN Standard designation Qty

e
1 550 542 89 CYLINDER TUBE 1
2 550 542 90 ROD, PISTON 50-643 1
3 155 044 48 PISTON 80/50 1
4 162 395 08 COVER, FRONT 80/50 1
5 817 317 59 RING, PISTON 80 X 60 X 22,4 1
. . . . .
6 803 135 09 SEAL, U 50x60x10, NI300 1
7 807 823 69 WIPER 50-60-7-10 1
8 522 271 70 O-RING 69.2x5.7 1
9 800 118 39 O-RING 79.5x3.00 1
10 428 702 10 O-RING 49.5x3.00 1
. . . . .
11 814 797 09 GUIDE RING, PISTON ROD 50/56X13 3
12 814 749 19 BEARING, PLAIN 2
13 810 765 99 SCREW, RETAINER M6X8 1
14 572 102 40 NIPPLE, GREASE AR 1/8 2
15 550 774 79 USIT-SEAL R1/2" 2
. . . . .
16 881 140 79 PLUG G1/2 2
*17 856 700 69 SEAL KIT 1
*17.1 817 317 59 RING, PISTON 80 X 60 X 22,4 1
*17.2 428 702 10 O-RING 49.5x3.00 1
*17.3 807 823 69 WIPER 50-60-7-10 1
. . . . .
*17.4 814 797 09 GUIDE RING, PISTON ROD 50/56X13 3
*17.5 803 135 09 SEAL, U 50x60x10, NI300 1
*17.6 800 118 39 O-RING 79.5x3.00 1
*17.7 522 271 70 O-RING 69.2x5.7 1
*17.8 801 802 69 BONDED SEAL d13,7xD22xs1,5 2
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 552 156 29 NSS
39 (57) PIPE, EXHAUST / MOUNTING 150824

1.1

1.4

1.2 2

564 513 207 1.4

563
6 5 3 173 4

1.3 173 510 563

Ref. Part no. Description EN Standard designation Qty

e
1 552 156 24 PIPE, EXHAUST NC7N 1
1.1 552 156 20 PIPE, EXHAUST Connecting pipe NC7 1
1.2 552 156 19 SILENCER, EXHAUST Silencer / Catalytic converter 1
1.3 552 156 21 EXHAUST PIPE Outlet pipe NC7N 1
1.4 552 156 23 CLAMP D88,9 2
. . . . .
2 552 156 46 BRACKET Exhaust silencer 1
3 552 156 65 WIRE ROPE L=1050 2
4 551 751 32 SUPPORTING BLOCK Exhaust pipe 1
5 550 716 62 WASHER 13 Ms 4
6 411 766 90 NUT, HEXAGON M12, A4 8
. . . . .
173 800 460 49 HEXAGON HEAD SCREW M10X25 - 8.8 2
207 800 532 09 HEXAGON HEAD SCREW M12X45 - 8.8 2
510 800 820 19 NUT, HEXAGON M10 - 8 1
513 800 821 49 NUT, HEXAGON M12 - 8 2
563 550 130 58 WASHER, LOCK, DOUBLE M10 sp 3
. . . . .
564 550 130 59 WASHER, LOCK, DOUBLE M12 sp 4

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 401 34 a
150824 DRIVE SHAFT / LZ=380 40 (57)

1 3 3 2

Ref. Part no. Description EN Standard designation Qty

e
*1 550 516 62 FLANGE Dia 120 mm 1
*2 550 516 63 FLANGE dia 150 mm 1
*3 550 516 61 CROSS-LINK Sliding shaft 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 907 46 a
41 (57) DRIVE SHAFT / LZ=640, LA=110 150824

2 1 1 2

Ref. Part no. Description EN Standard designation Qty

e
*1 550 516 63 FLANGE dia 150 mm 2
*2 550 516 61 CROSS-LINK Sliding shaft 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 881 956 69 b NSS
150824 DRIVE SHAFT / L=1070, UCP 42 (57)

3 2 1

Ref. Part no. Description EN Standard designation Qty

e
*1 883 283 39 FLANGE YOKE 1
*2 814 574 59 CROSS-LINK 1
*3 614 694 89 FLANGE 1
*4 815 498 69 BEARING, SUPPORT UCP209 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 569 81 cC NSS
43 (57) CABINET / BOX AND FASTENING PARTS 150824

4 1

Ref. Part no. Description EN Standard designation Qty

e
1 422 034 50 CIRCLIP 15X1 2
2 550 569 73 CABINET 1
3 550 570 67 CLIP 2
4 551 851 44 BEARING, BALL, DEEP GROOVE D28 d15 L7 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 799 02 aA NSS
150824 PLATE, COVER / ASSEMBLY, HEAT COVER 44 (57)

563
171

171
563

Ref. Part no. Description EN Standard designation Qty

e
1 551 798 73 PLATE, COVER Welding assembly, Heat cover, NC7N 1
2 551 798 79 PLATE, COVER Heat cover, NC7N 1
3 551 791 57 PLATE, COVER Heat cover, NC7N 1
171 800 432 79 HEXAGON HEAD SCREW M10X16 - 8.8 5
563 550 130 58 WASHER, LOCK, DOUBLE M10 sp 5
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 844 12
45 (57) WHEEL ASSEMBLY / 12.00-20 PR28 ECR HAULER 150824

2
s
ng 3 4
Ri
ck
Lo

Ref. Part no. Description EN Standard designation Qty

e
1 551 884 80 RIM 8.50 x 20 1
2 551 887 62 TIRE tyre set, including rim band and tube 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 670 73 aA NSS
150824 ACCUMULATOR, PRESSURE / BRAKES 46 (57)

4 5 6
7
13

12
3

10

9
11 21 600 22 600

Ref. Part no. Description EN Standard designation Qty

e
1 550 383 54 ACCUMULATOR Max oprating pressure 211 bar Size: 0,7l 2
2 550 596 29 PLATE Pressure accumulator 1
3 865 407 99 ADAPTER, HYDRAULIC JIC 3/4-16 2
4 819 563 69 ADAPTER, CROSS 3/4-16JIC 2
5 817 165 99 REDUCER, TUBE END 3/4X7/16JIC 2
. . . . .
6 818 001 09 NUT JIC 3/4-16 2
7 819 561 09 SWIVEL NUT ELBOW 90 JIC 7/16-20 2
8 156 959 48 PIECE, FASTENING M28x1.5-1/2-20UNF 2
9 850 819 99 SEAL, COPPER 13/26X1,5 2
10 807 590 69 VALVE Thread 1/2-20 UNJF-3A 2
. . . . .
10.1 869 733 29 O-RING 14.0x2.00 1
10.2 851 682 19 PROTECTING CAP Vg8 Av3/8" 1
11 085 370 18 CAP, PROTECTING D28, L34, RUBBER 2
12 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 2
13 817 097 49 PLUG JIC 3/4-16 2
. . . . .
21 552 203 37 SIGN F (30X35) 1
22 390 131 68 SIGN Letter R (30X35) 1
600 455 332 90 SCREW 2X5 8

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 552 039 05 a NSS
47 (57) ASSEMBLY / MEASURING ADAPTERS 150824

551

507

777

721

562 1 2 3 4

Ref. Part no. Description EN Standard designation Qty

e
1 552 037 79 BRACKET Collecting piece, measuring adapters 1
2 552 037 49 NSS MANIFOLD BLOCK SECTION 8 PAGE 48 1
3 552 038 07 PLATE Bracket, collecting piece, measuring 1
adapters
4 552 038 85 SIGN Carrier pressures 1
507 801 779 99 NUT, LOCK M8 - 8 6
. . . . .
551 851 281 89 WASHER, LOCK, DOUBLE M8 6
562 550 160 42 WASHER, LOCK, DOUBLE M8 sp 2
721 455 332 90 SCREW 2X5 4
777 813 903 69 HEXAGON SOCKET HEAD SCREW M8X65 m8.8 4

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 552 037 49 NSS
150824 MANIFOLD BLOCK / MEASURING ADAPTERS 48 (57)

3 4

2 8 1

Ref. Part no. Description EN Standard designation Qty

e
1 550 655 06 BLOCK, LUBRICANT FITTINGS 1
2 817 179 09 STRAIGHT THREAD ADAPTER JIC 7/16-20 7
3 871 692 89 PLUG G1/4 4
4 816 885 99 FITTING, QUICK CONNECT 6
5 851 975 79 STRAIGHT THREAD ELBOW 7/16-20 JIC 2
. . . . .
6 816 711 99 ADAPTER, ELBOW G 1/4 x JIC 9/16-18 1
7 816 705 99 SWIVEL NUT MALE ADAPTER 1/4 in 1
8 812 553 99 VALVE, SHUTTLE R1/4 INC 1

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 731 90 bA NSS
49 (57) DIPSTICK KIT / FOR TRANSMISSION OIL CHECK 150824

8 3

9 6

10

7
4

Ref. Part no. Description EN Standard designation Qty

e
1 551 731 93 DIPSTICK Dipstick, transmission oil check 1
2 551 718 32 HOSE hose, transmission oil check 1
3 551 729 16 NUT, ADAPTER adapter, 12JIC - inside G1/2 1
4 865 275 49 ADAPTER, TEE JIC 1,1/16-12 1
5 816 909 59 PLUG JIC 1 1/16-12 1
. . . . .
6 550 002 11 CLAMP, PIPE STAUFF 4030 PP 1
7 853 383 89 CONNECTOR, MALE 1,1/16-12JIC 1
8 550 002 14 CLAMP, PIPE COVER PLATE STAUFF DPAL 4S 3
9 800 529 89 HEXAGON HEAD BOLT M10X90 - 8.8 2
10 851 282 09 WASHER, LOCK, DOUBLE M10 2
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 735 16 NSS
150824 DEFLECTOR, AIR / ASSEMBLY, TOP 50 (57)

2 1

10 11 12

Ref. Part no. Description EN Standard designation Qty

e
1 551 735 17 PLATE Air guide plate, NC7N 1
2 551 735 20 RUBBER SHEET Air guide plate, top, NC7N 1
10 800 916 09 HEXAGON HEAD SCREW M8X25 - 8.8 9
11 801 779 99 NUT, LOCK M8 - 8 9
12 884 293 59 WASHER M8 18
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 732 32 NSS
51 (57) DEFLECTOR, AIR / ASSEMBLY, LEFT 150824

14

13 16

2 12 15 6 3

Ref. Part no. Description EN Standard designation Qty

e
1 551 732 34 DEFLECTOR, AIR 1
2 551 688 85 RUBBER SHEET 1
3 551 764 83 RUBBER SHEET 1
6 551 765 76 SUPPORT 1
12 800 916 09 HEXAGON HEAD SCREW M8X25 - 8.8 11
. . . . .
13 884 293 59 WASHER M8 22
14 801 779 99 NUT, LOCK M8 - 8 11
15 800 432 79 HEXAGON HEAD SCREW M10X16 - 8.8 2
16 550 130 58 WASHER, LOCK, DOUBLE M10 sp 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 732 31 NSS
150824 DEFLECTOR, AIR / ASSEMBLY, RIGHT 52 (57)

14

16 11 13

6 5 15 4 10 3 12

2 10 11

Ref. Part no. Description EN Standard designation Qty

e
1 551 732 33 DEFLECTOR, AIR 1
2 551 679 75 PLATE 1
3 551 734 65 PLATE 1
4 551 688 85 RUBBER SHEET 1
5 551 764 82 RUBBER SHEET 1
. . . . .
6 551 765 75 SUPPORT 1
10 851 281 89 WASHER, LOCK, DOUBLE M8 4
11 808 803 59 HEXAGON HEAD SCREW M8X16 - 8.8 4
12 800 916 09 HEXAGON HEAD SCREW M8X25 - 8.8 11
13 884 293 59 WASHER M8 22
. . . . .
14 801 779 99 NUT, LOCK M8 - 8 11
15 800 432 79 HEXAGON HEAD SCREW M10X16 - 8.8 2
16 550 130 58 WASHER, LOCK, DOUBLE M10 sp 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 398 44 cC NSS
53 (57) SHIELD, SPLASH / FRONT, LEFT 150824

564 513 206 4 262 565

3
206
351 557 513
2 206 513 564
564

351 557

Ref. Part no. Description EN Standard designation Qty

e
1 550 398 85 SHIELD, SPLASH 1
2 550 399 01 BRACKET, MOUNTING 1
3 550 115 58 BRACKET, MOUNTING 1
4 550 115 59 BRACKET, MOUNTING 1
206 800 531 79 HEXAGON HEAD SCREW M12X40 - 8.8 8
. . . . .
262 800 196 59 HEXAGON HEAD SCREW M16X30 - 8.8 2
351 442 934 50 HEXAGON HEAD SCREW M24X40 m8.8 3
513 800 821 49 NUT, HEXAGON M12 - 8 8
557 851 284 69 WASHER, LOCK, DOUBLE M24 3
564 550 130 59 WASHER, LOCK, DOUBLE M12 sp 16
. . . . .
565 550 130 61 WASHER, LOCK, DOUBLE M16 sp 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 550 441 51 dD NSS
150824 SHIELD, SPLASH / FRONT, RIGHT 54 (57)

1
4 206 513 564
555 262

564

513

206
351 557

206 513 564 2 557 351

Ref. Part no. Description EN Standard designation Qty

e
1 550 398 86 SHIELD, SPLASH 1
2 550 399 01 BRACKET, MOUNTING 1
3 550 115 58 BRACKET, MOUNTING 1
4 550 115 59 BRACKET, MOUNTING 1
206 800 531 79 HEXAGON HEAD SCREW M12X40 - 8.8 8
. . . . .
262 800 196 59 HEXAGON HEAD SCREW M16X30 - 8.8 2
351 442 934 50 HEXAGON HEAD SCREW M24X40 m8.8 3
513 800 821 49 NUT, HEXAGON M12 - 8 8
557 851 284 69 WASHER, LOCK, DOUBLE M24 3
564 550 130 59 WASHER, LOCK, DOUBLE M12 sp 16
. . . . .
565 550 130 61 WASHER, LOCK, DOUBLE M16 sp 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 737 59 fF NSS
55 (57) MUDGUARD ASSEMBLY / REAR, RIGHT 150824

5 8 4

12 11 10 7
1

2 3

Ref. Part no. Description EN Standard designation Qty

e
1 551 737 68 PLATE 1
2 551 737 70 PLATE 1
3 551 737 71 PLATE 1
7 551 691 13 PLATE, BACKING REAR MUD GUARD 1
10 550 130 61 WASHER, LOCK, DOUBLE M16 sp 4
. . . . .
11 442 219 80 HEXAGON HEAD SCREW M16X50 - 8.8 2
12 811 259 69 NUT, LOCK M16 - 8 2

Sandvik Mining and Construction Oy, Drills Tampere © 2015

 551 737 58 hI NSS
150824 MUDGUARD ASSEMBLY / REAR, LEFT 56 (57)

A 5 4 13

1 SECTION A - A
A
2
12
11
10

Ref. Part no. Description EN Standard designation Qty

e
6 551 739 20 PLATE Mud guard 1
7 551 691 13 PLATE, BACKING REAR MUD GUARD 1
10 550 130 61 WASHER, LOCK, DOUBLE M16 sp 4
11 442 219 80 HEXAGON HEAD SCREW M16X50 - 8.8 2
12 811 259 69 NUT, LOCK M16 - 8 2
. . . . .

Sandvik Mining and Construction Oy, Drills Tampere © 2015
